Creaform Scan-to-CAD is a professional reverse engineering software module designed to convert 3D scan data into accurate CAD models. As part of the Creaform Metrology Suite, it provides powerful tools for mesh processing, geometry extraction and seamless integration with leading CAD platforms.

The software enables engineers and designers to transform raw 3D scan data into usable, optimized meshes suitable for product development, prototyping and 3D printing workflows. With fast processing capabilities, Scan-to-CAD accelerates the transition from scanning to CAD modelling.

Scan-to-CAD includes a complete set of mesh editing tools such as cleaning, hole filling, merging, decimation and watertight mesh generation. The software also provides advanced alignment tools, allowing users to position scan data accurately within a coordinate system using best-fit or entity-based alignment.

The solution simplifies reverse engineering by enabling extraction of geometric features directly from mesh data. Users can generate surfaces, curves, cross-sections and 2D/3D entities, which can then be exported into CAD environments for further modelling.

Scan-to-CAD supports standard CAD formats including IGES, STEP and DXF, and integrates with major CAD platforms such as SOLIDWORKS, Autodesk Inventor, Fusion 360 and Solid Edge.

Key features include:

• mesh cleaning, optimization and repair tools
• hole filling, mesh merging and decimation
• watertight mesh generation for 3D printing
• alignment tools (best-fit and entity-based)
• extraction of geometric entities and surfaces
• cross-sections and curve generation
• export to IGES, STEP and DXF formats
• integration with leading CAD software

Creaform Scan-to-CAD software is widely used in reverse engineering, product development, industrial design and additive manufacturing workflows.
