EQUIPMENT DETAILS

The RS10 Robotic Total Station has an auto aim function,with a brand new intelligent algorithm to accurately and automatically correct the angle reading deviations when sighting.

This technology enables the robotic total station to quickly complete the target search and accurately determine the center position of the prism,ensuring greater workefficiency in various working environments.

The RS10 robotic total station system launched by FOlFis ameasurement system integrating automatic target recognition, automatic aim, automatic angle measurement and ranging, automatic target tracking, and automatic  recording

Features

Bring the survey into the era of automation,and provide the surveyors with more efficient and convenient automation measurement solutions. The instrument provides a more cost effective option for deformation monitoring, cross-section measurement,etc. It realizes the automation from field data collection to result calculation and output, and significantly improves the efficiency of indoor and outdoor work, greatly reduces the labor intensity of people,eliminates various errors, and can also reduce the requirements of traditional measurement methods for people and equipment.As long as you simply master the basic operations,you can proceed with the  indoorand outdoor work.

Power-driven focusing

• Focusingis steady and convenient

Integrated    compensatin

• The high-precisionintegrated compensator is placed in the axis, and the compensation is fasterand more stable

Diversified communication interfaces

• Bluetooth,RS232communication,4Gallnetworks,which meet the needs of customers for remote  command  control

Direct Drive Technology

• Withanew generation of direct-drive motor,the maximum speed can reach 180°/s,and it can realize high-resolution angle fine-tuning and high-precision positioning

Abundant customization of measurement functions

• Autoaim
• Autotrack
• Intelligent   recognition
• Telemetering control

High level of protection, rugged and easy to operate

• It has a high level of waterproof and dustproof performance

The Android-style graphical operation interface makes it easy for you to get started

• Built-in  Android operating system
• Large touchscreen operation and graphical interface

Professional measurement guides to helpyou finish a wide range of applications with ese

Perfectmeasurement and stakeout functions, offset measurement, resection, road measurement, crossectional measurement, opposite side measurement, multiple observations, etc.

• Practicalengineeringapplicationfunctions such as road measurement and design,cross-section measurement,etc
• The  motor-driven  automatic  scanning,automaticmonitoring,etc.
• AbundantCOGOtechnical functions,coordinate inverse and traverse calculation,intersections calculation,angle calculation, offset  calculation,curve  calculation,area  calculation,etc
• Dataimport  and  expor  function  in  a  variety  ofcommonlyused  formats

Specification

Model | RS10
Telescope
Magnification/Resolution | 30×/3"
Field of view | 1°30′
Shortest focusing distance | 1.5m
Effective aperture | φ50
Imaging | Erect
Angle Measure
Accuracy | 0.5” 1”
Method | Absolute encoder
Unit | 360°(dms/d)/400gon/6400mil
Min.display | 0.1"
Distance Measure |
Accuracy Prism | ±(1+1×10⁶D)mm
Reflective sheet | ±(2+2×10⁶D)mm
Reflectorless | ±(3+2×10⁶D)mm
Range Standard prism(remote prism mode) | 2~5000m
Reflective sheet | 1~800m
Mini prism | 2~1200m
Reflectorless | 1~1000m
Time Fine/Fast/Track | ≤1.0s(initial 1.5s)/≤0.5s(initial 1.0s)/≤0.2s(initial 1.0s)
Unit | m/ft/USft
Min.display | 0.0001m/0.001m(Fine、Fast),0.01m(Track)
ATR
Woring range | 5m~1000m
Basic positioning accuracy | ±1.5mm@≤200m,±1.5”@>200m
Positioning time(in field of view of telescope) | 0.5s~2s
Motor drive
Max.rotational angular speed | 180°/s
Min.value for micro-rotation control in low speed | 1”
Tilt compensation
Compensation method | Integrated dual-axis type
Compensation range | ≥±6.0′
Level vial sensitivity |
Plate level vial | 30”/2mm
Circular level vial | 8'/2mm
Laser plummet
Accuracy | ±1.0mm/0.8m~1.5m
Laser spot | ≤2.0mm/0.8m~1.5m
Power |
Battery | 11.1V,5800mAh lithium battery
Working time | 5h-8h
Other |
Endless drive | 1 for horizontal,1for vertical
Display | 6-inch touchscreen,resolution 1280*720,double displays,single display working supported
Keyboard | 15 keys at the bottom,backlight illumination+automatic sensitivity to light
Communication port | USB to RS232,USBC port,USB HOST port,close-range BT standard,long-range BT(optional),various networks(4G optional)
Function support | Trigger key/buzz output/speaker/TF card/Temp.and air pressure sensor /cloud update
System | ANDROID11.0,quad-core 64-bit ARM A55 CPU 2GHz,8GB+128GB
Protection grade | IP55(IEC60529)
Working temp.range | -20℃~+50℃
